The Magmatic MAGMA PRIME II is the second generation of the crowd-favorite Magma Prime, redesigned with enhanced features and functionality based on customer feedback. This professional 700W water-based fazer combines the atmospheric effects of a hazer with the technology of a traditional fog machine, producing a steady, consistent output of fine fog to enhance lighting effects without the large bursts typically associated with conventional fog machines.
Delivering up to 4,000 CFM (113 m³/min) of atmospheric output, the MAGMA PRIME II is ideal for mobile entertainers, nightclubs, theaters, concert productions, and other entertainment applications requiring consistent atmospheric effects.
You asked, and we listened! The MAGMA PRIME II introduces several improvements, including an automatic priming function for convenient fluid system preparation, an integrated hanging bracket that doubles as a handle for easy transportation and truss mounting, Over Voltage Protection (OVP) for added electrical protection, and Sleep Mode for improved operational convenience.
Equipped with a thermally protected heat exchanger, the MAGMA PRIME II features an initial warm-up time of approximately 6 minutes. Its sealed 1.3-liter (0.345-gallon) fluid reservoir includes external visual fluid level detection, allowing users to easily monitor fluid levels during operation. The unit is designed for use with Atmosity Extreme Filtered Fog Fluid for optimal performance.
The MAGMA PRIME II offers versatile control options, including an onboard LCD touch control panel, DMX-512 with four selectable channel modes (1, 2, 3, and 5 channels), and RDM support for remote device management. Optional accessories include a wireless DMX transceiver module and MAGRF wired and wireless remote controls, providing additional flexibility for a variety of installations and applications.
Designed with portability and convenience in mind, the MAGMA PRIME II features a compact, lightweight housing with an integrated hanging bracket/handle for flexible mounting options. Locking 5-pin XLR DMX input/output connections and an IP65-rated locking power input connector provide secure connectivity.
Weighing just 22.48 lbs. (10.2 kg), the MAGMA PRIME II combines the proven performance of the original Magma Prime with enhanced functionality, flexible control, and a compact design, making it an excellent choice for creating consistent atmospheric effects in professional entertainment environments.
Technical Data
FEATURES
Second-Generation MAGMA PRIME Water-Based Fazer Professional 700W Heating System Maximum Atmospheric Output: 4,000 CFM (113 m³/min) Steady, Consistent Fog Output for Haze-Like Atmospheric Effects Approximately 6-Minute Initial Warm-Up Time Automatic Priming Function Integrated Hanging Bracket/Handle for Truss Mounting and Transportation Over Voltage Protection (OVP) Sleep Mode Function Thermally Protected Heat Exchanger 1.3-Liter (0.345-Gallon) Sealed Fluid Reservoir External Visual Fluid Level Detection Onboard LCD Touch Control Panel DMX-512 and RDM Protocol Support 4 Selectable DMX Channel Modes (1 / 2 / 3 / 5) Optional Wireless DMX Transceiver Module Optional MAGRF Wired and Wireless Remote Controls Locking 5-Pin XLR DMX Input/Output Connections IP65-Rated Locking Power Connectors Compact, Lightweight, Portable Design cETLus, CE, and FCC Approvals IP20-Rated Housing
PERFORMANCE
Type: Water-Based Fazer Generation: Second Generation Rated Power: 700W Maximum Atmospheric Output: 4,000 CFM (113 m³/min)* Initial Warm-Up Time: Approximately 6 Minutes* Fluid Capacity: 0.345 Gallons (1.3 Liters) Fluid Consumption: 0.115 oz/min (3.4 ml/min) Automatic Priming: Yes Sleep Mode: Yes Over Voltage Protection (OVP): Yes Compatible Fluid: Atmosity Extreme Filtered Fog Fluid AEF-2L (2-Liter) AEF-4L (4-Liter) AEF-20L (20-Liter)
Control Protocols: DMX-512 / RDM DMX Channel Modes: 1 / 2 / 3 / 5 Channels Onboard LCD Touch Control Panel Optional Wireless DMX Transceiver Module Optional MAGRF Wireless Remote Control Optional MAGRF Wired Remote Control
CONNECTIONS
DMX Input: Locking 5-Pin XLR DMX Output: Locking 5-Pin XLR Power Input: IP65-Rated Locking Power Connector
ELECTRICAL
Input Voltage (US): AC 120V, 60Hz Input Voltage (EU): AC 230V, 50Hz Current Draw (US): 9A @ 120VAC (NFB) Current Draw (EU): 5A @ 230–240VAC Maximum Power Consumption: 720W Thermal Maximum Ambient Temperature: 104°F (40°C) Exterior Surface Temperature (Steady State): 122°F (50°C)
