Code
1226100222
FEATURES
IP65 Rated
45° Beam Angle, 15° and 25° Beam Angles Optional
No-Service Convection Cooled
Flicker Free Operation for TV and FILM
Rugged Die-Cast Aluminum Exterior
Multiple Unit Power Linking
SOURCE
36x 2W UV LEDs
50,000 Hour Average Life
PHOTOMETRIC DATA
UV: 395nm
EFFECTS
Electronic Strobe 1-25FPS
Electronic Dimming: 0% - 100%
CONTROL / CONNECTIONS
(2) DMX Channel Mode (1/2)
(4) Button Control Panel
Color LCD Menu Display
IP 3pin DMX In/Out
IP 3pin Power In/Out
SIZE / WEIGHT
Length: 315mm
Width: 269mm
Vertical Height: 368mm
Weight: 7kg
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz
90W Max Power Consumption
Multiple Unit Power Linking
-25°C to 45°C
Specifications and documentation subject to change without notice
