Trackpod 84A LED Bar

- 840 high output 5mm LED´s
- Full video pixel mapping control
- 40 sections
- 15° beam angle
- Up to 160 DMX channels
- 19 built-in programs
- Flicker free

Specifications
- 840 LEDs - (280 Red, 280 Green, 280 Blue)
- Seamless RGB color mixing
- Infinite Color possibilities
- 15-degree beam angle
- 2300 LUX @ 1M / 1000 LUX @ 2M
- Long Life L.E.D. (rated at 100,000 Hours)
- Low power consumption
- Low heat emissions
- Built-in Power Supply and DMX 512 Control
- Flicker free operation for television and film (520Hz)
- Electronic Switching Power Supply (90-260V, 50/60Hz)
- Full video pixel mapping control. LEDs are arranged in ten modules of 84, each of which can be divided into four individual sections. This provides a total of 40 pixels capable of running graphics or matrix when multiple units are used together.
- USITT-DMX 512
- 4, 7, 8, 20, 40, 160 control channel modes
- LCD display with 4-button DMX control
- 3-pin and 5-pin XLR in/out
- 4 control modes: DMX; Master/Slave; Manual Color Mix; Auto Chase
- 19 pre-programmed chases
- Strobe effect
- 7 static colors with intensity control
- 0-100% Dimming
- 100-240V AC, 50/60Hz (Multi-voltage)
- Powercon for power connection
- Power Consumption: 120 watts
- Heavy duty mounting bracket
- Dimensions (LxWxH): 1010x258x245mm
- Weight: 11.3 kg
