Show Designer 3

- 3 DMX Universes
- 48 fixtures
- 32 channels per fixture
- Additional 128 dimmer channel
- Effects generator
- Large fixture profile library
- 16 chases & 17 shows simultaneously

Specifications
- 3 DMX Universe, 3 & 5 Pin connectors on each output
- Control 48 moving light fixtures up to 32 channels each
- Control 128 Conventional dimmers additional
- Playback scenes using buttons or playback faders
- Effect generator to create chase effects
- Conventional dimmers can be included in scene memory or be independent.
- Factory ready color, gobo, focus & effect presets
- Large moving light fixture library available (same profiles as Show Designer 2)
- Scene preview with “Go” button
- Solo feature allows scenes to track through or play solo
- Scenes can be combined and recorded as new scenes
- Scenes, shows, chases and presets can be assigned to the playbacks
- Playbacks can manually fade channels (LTP mode) or trigger timed fades while manually controlling dimmer levels (HTP mode)
- 4752 programmable scenes
- 1152 programmable chases
- 1152 programmable shows
- 1152 programmable presets
- 80 Character backlit display for easy programming
- 4 menu and control data wheels
- 48 Multi function Quick access buttons
- 100mm faders
- 8 dedicated playback faders with 32 pages
- 8 flex faders with page selection for moving light channels, conventional dimmers or additional playbacks.
- Pan/tilt joystick with coarse/fine control
- Grand master fader
- Flex master fader
- Go, stop and back buttons
- Blackout, audio and beat buttons
- 2 USB LITE connectors (for gooseneck lamps)
- Midi-In port
- CF-drive for memory back up, loading fixture profiles and software updates.
- PS2 Keyboard input
- RS-232 Port, for PC interface
- RCA Audio input for Chases
- Fade times up to 90 minutes
- Large moving light fixture library available
- Software updates available at www.elationlighting.eu
- 230/110V AC power supply
- Dimensions: 711x584x178mm
- Weight: 17kg
