- 6 x 20A in only 2U
- 20 A per channel
- High quality chokes
- Channel presets
- DMX fail backup
- Real time zero crossing detection
- Individual dimmer curves
Specifications
- 6 channel digital dimmer pack
- USITT DMX-512 (3-pin) input
- 2U 19” rack mount
- High speed micro processor
- Real time zero crossing detection
- Backlit digital display
- High quality chokes for minimal noise
- Individual or block channel patching
- Minimum channel output setting from 0 to 30%
- Maximum channel output setting from 70 to 100%
- Channel curve setting option includes Linear, Square,
- Non Dim and S-Curve - individually assignable for each channel
- DMX fail backup feature- contains 12 internal chase programs, last scene hold and Analog - control options
- Power failure memory
- Standard Terminal type output panel
- DMX Output
- Analog input
- Fan cooled
- 6 x 20A UL approved MCB breakers
- 20A/CH. Total 120A single phase connection
- 20A/CH. Total 40A per phase- three phase connection
- Dimensions (LxWxH): 432x483x89mm
- Weight: 9,5kg
- Power requirement: AC 240V/50Hz.
