PLATINUM SPOT 5R WH

Code: 1237000029

- Revolutionary Philips MSD Platinum 5R Lamp
- 22 Gobos (14x stat./ 8x rot.)
- 8 Colors
- Prism / Iris / Focus
- Stepless Frost (Hybrid)
- Pan: 540° or 630°, Tilt: 265°
- Only 12,9kg / 36x34x45 cm

2000 hour rated lamp source
- Philips MSD Platinum 5R lamp (7950lumen, 8000°K, 2000h) included
- 15290 Lux @ 2,5m
- 16° beam angle
- 1 color wheel with total 8 colors + white
- Variable speed color scrolling in both directions (rainbow effect)
- 2 gobo wheels with total 22 gobos, 8 interchangeable (quickout)
- First wheel: 8 indexable, rotating gobos plus open
- Second wheel: 14 static gobos plus open
- Variable speed gobo scrolling in both directions
- Gobo Overlay (gobo morphing)
- Gobo Size: 14.0mm outside diameter, 8mm image diameter
- Rotating, indexing prism: 3-facet
- Variable speed iris with macros (5-100%)
- Variable Frost Filter (Hybrid effect for Wash)
- Dual flag mechanical dimming system
- Variable speed strobe effect
- Preset variable/random strobe and dimming pulse effects
- Motor driven focus from near to far
- Automatic Pan / Tilt position correction
- Maximum Pan-movement 630° or 540°/ 16 bit
- Maximum Tilt-movement 265° / 16 bit
- 3 Phase motors for fast and accurate Pan / Tilt positioning
- Vector Mode with blackout MIB function
- Battery powered blue LCD Matrix Display
- 16 DMX channels USITT DMX-512 (16-bit resolution)
- Customizable DMX channel assignment
- DMX, stand-alone, master/slave or sound activated mode
- DMX recorder and edit function integrated
- 3-pin and 5-Pin XLR serial input/output
- Fan cooled - fans regulated by automatic, silent or DMX
- Constant temperature readout and management function
- DB rating @ 1M = 54,18db
- 1x 1/4 turn fastening Omega Clamps
- Electronic ballast and power supply
- Power consumption: 342W max.
- Voltage: AC 100V ~ 240V 50/60Hz
- Dimensions (LxWxH): 360x337x450 mm (Head up)
- Weight: 12,9 kg
