- Razor Sharp 3° Very Narrow Beam
- Variable Zoom And Focus (Motorized)
- Stepless Frost (Hybrid), 5 Facet Prism
- 12 Dichroic Colors & Ultra-Brightness
- Uses Philips MSD Platinum 15R Lamp
- 17 Rotating / Indexing Gobos
- Only 22kg / 40x37x63 cm
- 1500hour rated lamp source
- Phillips MSD Platinum 15R lamp (13500lumen, 8000°K, 1500h) included
- 3° beam angle (variable)
- Zoom and Focus (motorized)
- 72500 Lux @ 5m
- No need for cleaning or adjustment of reflector or lamp
- All lenses are anti-reflection coated
- 1 color wheel with total 12 colors + white
- Variable speed color scrolling both directions (rainbow)
- First wheel with 8 rotating and interchangeable (quickout)
- Second wheel with 9 static gobos plus open
- Variable speed gobo scrolling in both directions
- Gobo Size: 14.0mm outside, 6mm image diameter
- Rotating, indexing prism: 5-facet
- Macro-function for rotating gobo/prism combinations
- Variable Frost Filter (Hybrid effect for Wash)
- Dual flag mechanical dimming system
- Variable speed strobe effect
- Preset variable/random strobe and dimming pulse effects
- Automatic Pan / Tilt position correction
- Maximum Pan-movement 630° or 540°/ 16 bit
- Maximum Tilt-movement 265° / 16 bit
- 3 Phase motors for fast, accurate Pan / Tilt positioning
- Vector Mode with blackout MIB function
- Battery powered and colored LCD Display
- 22 DMX channels USITT DMX-512 (16-bit resolution)
- Other DMX modes available
- Customizable DMX channel assignment
- DMX, stand-alone, master/slave, sound activated mode
- DMX recorder and edit function integrated
- Software update via DMX, using optional E-Loader
- 3-pin and 5-Pin XLR serial input/output
- Fan cooled - fans regulated by automatic, silent or DMX
- Constant temperature readout / management function
- DB rating @ 1M = 54,18db
- 2 x 1/4 turn fastening Omega Clamps
- Electronic ballast and power supply
- Power consumption: 475W max.
- Voltage: AC 100V ~ 240V 50/60Hz
- Dimensions (LxWxH): 408x370x639 mm
- Weight: 22 kg
