- Full RGB spectrum available
- 180 SMD- RGB LEDs on 3m
- 16,6mm pixel pitch
- 120° light dispersion
- Extreme wide temperature range
- Extreme bright and flexible RGB-LED tape of 3 meters length with 180 SMD-RGB LED`s
Specifications
- 3 meters length on a roll, 11,5mm wide
- 3 colors on one chip
- 16,6mm space between LEDs
- dividable every 50mm, which makes 3 LEDs = 0,72W
- Bright RGB colors
- Easy to use connector system
- Voltage: 12V
- Rated power: 14,4W/meter
- Total power consumption 3m: 43 watts.
- Beam Angle: 120°
- Operating Temperature - -40°c to 80°c
- Avg. Rated Life 30,000hrs
- LED Spacing 16.6mm (.65”)
- Dimensions 11.5mm (.45”) W x .15mm (.005”) D
Setup Options:
Full RGB DMX control:
304084 ELAR LED Driver 1
304102 FLEX PSU4a
Full RGB wireless control:
304098 FLEX RGB C
304027 WR LED
304102 FLEX PSU4a
For control of more than 3m Flex RGB you need every 3m:
304099 FLEX RGB AMP
304102 FLEX PSU4a
For connection (optional):
304100 FLEX EC3m Extension Cable for RGB Flex
304101 FLEX EC20cm Extension Cable for RGB Flex
