- Ultrabright RGB Pixel Technology
- 37.5 mm Pixel Pitch
- 2000 nits Luminosity
- 256 Pixel Per Tile
- Very Light Weight
- Flexible Mounting System
- IP 65 Waterproof
Ideal for both Outdoor and Indoor video display, the EVLED Strip Video Screen is a light weight, plug and play Video Mesh Tile module system using RGB LED`s capable of outputting up to 16.7 million colors. It is easy to handle, super-thin, semitransparent design makes it ideal for small or large applications. Integrated rigging fly support hardware and easy of set up make this system ideal for a variety of portable or permanent applications. Aluminum-alloy construction makes it rugged and durable. The product comes available in 37.5mm 18.75mm pitch resolution. Connect up to 1,000 Tiles from one Ethernet based input signal from our EVELED VSC processor and software makes set up and control easy. Road cases and rigging hardware are optional.
Specifications
- Light Weight Low Resolution Transparent LED Video Screen
- Pixel Pitch : 37.5 mm (1.5"")
- Transparency: 55%
- Curtain Composition: Al-alloy frame, electronics onboard w/ rubber gasket for weatherproof IP 65 rating
- Tile Size: 600 X 600 X 75 mm/tile (2 x 2)
- Tile Weight: 4.5 kg/tile
- Tile Area: 0.36m2/tile
- Luminosity: 2000 nits
- Color Temperature: 6500 k
- Visual Angle 110 / 50
Additional documents
Connection Maps-
EVLEDPL Panel Lock for EVLED25
Code: 1239100002
-
EVLED8RC 2,5m steel rigging cable
Code: 1239100004
-
EVLED11RC 3m steel rigging cab
Code: 1239100005
-
EVLED IMAGE VSC
Code: 1239100064
-
EVLED VSC Panel Control Inferf
Code: 1239100001
-
EVLED VSCII Panel Control Inte
Code: 1239100024
-
EVLED VSCSC Panel Control PCI
Code: 1239100025
-
EVLED VSCSCII Panel Control In
Code: 1239100026
-
EVLED VDS8 - 8 way data splitter
Code: 1323000004
