EVLED1024 SMDF Video Screen

- 3-1 SMD Tri-Color LED Technology
- 20mm pixel pitch
- 1,100lbs per tile section weight bearing
- Video signal supplied via Ethernet from EVLED VSC
- Power / Data Linkable
- Panel Clip lock system
- Aluminum Alloy structure

Model:    EVLED-1024SMDF
Transparency:   0%
Curtain Composition:  Al-alloy frame, rubber
   compound for weatherproof
Tile Size:   25.2 X 25.2 X 4 in/
   tile 640 X 640 X 103 mm/tile
Tile Weight:   44 lbs/tile 20 kg/tile
Tile Area:   0.4096m2 /tile
Pixel Pitch:   20 mm
Luminosity:   1500 nits
Color Temperature:  6500 k
Visual Angle:   110 / 110
