Elar EX Triflood

- 15x 3W TRI LEDs (= 45 W Power)
- 40° beam angle
- IP 65 outdoor rated
- Stand-alone programs
- Superior color mixing
- No-service convection cooled
- No colored shadows

The Elar EX Tri-Flood from Elation Architectural is an IP65 rated exterior LED Flood featuring tri-color RGB LED diodes. With a total power consumption of 60Watts the Elar EX Tri-Flood is an energy effi cient fi xture capable of providing a smooth wash effect. Set up and control is done via a wireless remote IR receiver which is on the face of the unit. Once set up, the unit can be operated from DMX with 4 different DMX control modes, and features built in macro programs all of which can be accessed via DMX or the optional wireless remote IR controller. The Elar EX Tri-Flood has been designed and built with a rugged aluminum die cast housing and internal thermal protection to ensure long life and operation.

Specifications

- 15 x 3 Watt Tri Color LEDs RGB (3-in-1)
- 40° Beam Angle
- IR Wireless Remote Setup and DMX control
- IP 65 Rugged Die Cast Aluminum Case Design
- USITT DMX 512
- DMX Channels: 6 DMX Channels,
- 4 DMX Modes: 3, 4, 5 or 6
 - Internal programs, dimming mode, auto run, master slave
- Built in Microphone
- Holds last state when power off
- No external controls
- Daisy Chain Units Together in DMX Mode
- Electronic Switching Power Supply
- Power Consumption: 60W
- Power Supply: 90V ~ 240V/60~50Hz
- Dimensions: 178 x 305 x 241mm
- Weight: 4.5 Kg
- ELAR WR is optional and sold separately,
