- DMX packet, format, timing, level testing
- Multiple DMX Receive data display
- Records incoming DMX
- Builds Cues Memories Chases
- Fixture library
- Easy channel testing
- Multiple language display
The DR DMX II allows you to check any DMX signal using multiple parameters as well as generating DMX sequences for testing purposes or as back up. The DR DMX II comes packed in a stable case with charger for the built-in battery.
Specifications
- ABS plastic mold body with matted black finish
- Professional DMX-512 & MIDI tester
- Analog/ Digital cable test
- DMX packet, including data format, data timing and data level (volt), can be tested
- Receiving DMX data, i.e. RX, can be displayed in Barchart, Value or Min/Max mode
- Transmitting DMX data, i.e. TX, has four options: 512 channel, Single channel, Cue/Memory and Run Cues(Scenes)
- RX data can be saved as cue, whereas the cue can serve as TX data
- Up to 15 cues can be saved and replayed, and be cleared
- Start code TX (0-255), Hold/ Normal RX display, DMX polarity
- Fixture library is editable, with a maximum of 10 fixtures, up to 36 channels per fixture
- Up to 10 fixtures can be tested with selectable starting address
- User-friendly operating and help information
- Text version Supports English, Spanish, German, French and Italian
- 4x20 characters LCD backlit display with adjustable contrast
- Dial wheel for access of menus and data entry
- 3-pin & 5-pin XLR male & female socket
- Power Requirement: DC 9 V, 500mA(powered by built-in, rechargeable battery, adaptor included)
- Dimensions: 300x270x100 mm (Case)
- Weight: 2.2 kg
