DR-512

- Records any DMX data streams
- Easy playback on press of a button
- Remote DMX trigger of playback
- SMPTE playback trigger
- Analogue switch remote trigger
- Start-up / shut-down sequences
- Back-up shows on CF-Cards

The DR-512 allows you to transfer lighting shows into this DIGITAL real time recorder and play back using either of the playback sequence buttons. Furthermore professional trigger and playback functions can are available.

Specifications
- 4 Sequences playback
- Record, Play, Pause & Stop
- Show start by DMX trigger
- SMPTE synchronization of playback
- 24/25/30 Frames SMPTE Signal
- Analogue control of play/start/stop/Seq./ Record and status Led´s by 9-pin terminal.
- DMX Back-Up Function on DMX loss
- Playback Sequence list on Power-On
- Separate Power-up and Shut-down Seq.
- 1MB built in memory
- 32MB Compact Flash Card Slot
- 2 x 16 character LCD display
- 3&5 Pin DMX XLR in/out
- 3 Pin SMPTE XLR in/out
- 19" Rackmount (1 space)
- Power: 9VDC 0,5A
- PSU: 110-240VAC 50/60Hz (included)
- Dimensions: 482x120x44mm (LxWxH)
- Weight: 1,6kg
