DMX Duo (DMX recorder)

The most easiest way to control your full light show without
complex DMX boards. Simple show assignments, additional
FX Controls, freely programmable chases. Build full shows
out of the stored single steps with added timings. First input
any DMX data from any external DMX light control, store
the steps, then arrange as you like and build complex
programs out of it. Always with keeping full control of your
additional light effects, fog machines and strobes. Use the
additional RS-323 Backup Software to store your full control
setups onto PC and back it up.

Specifications
- Single space DMX Recorder / Controller
- Accepts DMX information from any standard DMX controller
- 96 DMX channels (intelligent lights)
- 8 DMX FX channels (on/off effects)
- FX Timer (1, 3, 5, & 10 intervals)
- Separate DMX outputs for FX and Intelligent lights (outputs
  on rear)
- 8 Chases (99 steps each)
- 2 Shows (99 steps each, programmable hold & fade
  times)
- Mix or Sequence playback for chases and shows
- Audio trigger
- Manual trigger
- USB gooseneck light input
- Separate speed and fade control
- Strobe button (programmable)
- Machine input and trigger button
- RS232 (input on rear)
- 3 pin XLR In/Out (intelligent lights)
- 3 pin XLR (FX Out)
- Optional USB Light available
- Dimensions: 76x483x44mm – 1U 19” rack space
- Weight: 0,9 kg
