DMX-16-SW

- Switches 16 DMX channels
- Easy DMX address setting
- Link up to 32 DMX 16 SW
- Green led channel indicators
- LTP or HTP mode
- Power supply included
- Low profile 19” design

It can´t be easier: Switch on and off any of the 16 DMX
channels of the DMX-16-SW. The unit start address is adjustable
via dipswitch. Use it to trigger Switchpacks or even
light effects. You can also switch RGB channels and realize a
7 color mixing on up to 5 LED fixtures.

Specifications
- 16 Channel DMX switch controller
- 16 ON/OFF switches
- 16 Green Led channel indicators
- Link up to 32 DMX-16SW`s via 3 pin XLR Input/Output
- Addressable via 10 set dip switches
- LTP/HTP selectable operation modes
- On/Off power switch
- Power Input: 9VDC-200ma power supply
- Dimensions: 482x82x44mm, 19", 1U
- weight: 1,2kg
