SPECIFICATIONS
- 4 channel DMX Bar
- 16 built in Chase patterns
- Chases run by audio and preset Slow, Medium, & Fast
speeds
- DMX control activates Stand by, 16 built chases, 7 built in
scenes and 4 channel-manual dimmer mode to be controlled
by external DMX controller
- 7 built in static Scenes to be played back by DMX
- Linkup function for Master/Slave modes
- One three prong Edison socket per channel
- Four LEDs display channel activity
- External channel fuses for quick and easy replacement
- 3 pin XLR DMX Input & Output
- One jack 6,3mm foot controller input
- 4 mounting knobs for Par Cans
- 1 adapter for stand mount
- Control via DMX with the Elation; DMX Operator Pro,
Scene Setter, Scene Setter-48 and Stage Desk-16, DMX
Operator I, DMX Operator II
- Optional foot controller
- 4 IEC male plugs included
- Maximum Load: 5A per channel / 15A total
Manual EN
