Platinum Spot 15R Pro

- Zoom 9° to 27° / Prism / Iris / Focus
- CMY color mixing / 8 Colors
- Uses New Philips MSD Platinum 15R Lamp
- 22 Gobos, 14x stat. / 8x rot.
- Stepless Frost (Hybrid)
- 1/3 size @ output of 700-1200 Watt fixture
- Only 22kg / 41x42x54 cm

- 1500 hour rated lamp source
- Phillips MSD Platinum 15R lamp (13500lux, 8000°K, 1500h) included
- 84200 Lux @ 2,5m @ 9°
- 9° to 27° beam angle
- No need for cleaning or adjustment of reflector or lamp
- All lenses are anti-reflection coated
- CMY gradual color mixing 16bit
- 1 color wheel with total 8 colors + white
- Variable speed color scrolling both directions (rainbow)
- 2 gobo wheels, 22 gobos total, 8 interchangeable (quickout)
- First wheel: 8 indexable, rotating gobos plus open
- Second wheel: 14 static gobos plus open
- Variable speed gobo scrolling in both directions
- Gobo Overlay (gobo morphing)
- Gobo Size: 14.0mm outside, 8mm image diameter
- Rotating, indexing prism: 3-facet
- Macro-function for rotating gobo/prism combinations
- Variable speed iris with macros (5-100%)
- Variable Frost Filter (Hybrid effect for Wash)
- Dual flag mechanical dimming system
- Variable speed strobe effect
- Preset variable/random strobe and dimming pulse effects
- Motor driven focus from near to far
- Motor driven zoom 9° - 27°
- Automatic Pan / Tilt position correction
- Pan / Tilt Lock
- Maximum Pan-movement 630° or 540°/ 16 bit
- Maximum Tilt-movement 265° / 16 bit
- 3 Phase motors for fast, accurate Pan / Tilt positioning
- Vector Mode with blackout MIB function
- Battery powered and colored LCD Display
- EWDMX receiver for wireless DMX built-in
- 21 DMX channels USITT DMX-512 (16-bit resolution)
- Other DMX modes available
- Customizable DMX channel assignment
- DMX, stand-alone, master/slave, sound activated mode
- DMX recorder and edit function integrated
- Software update via DMX, using optional E-Loader
- 3-pin and 5-Pin XLR serial input/output
- Fan cooled - fans regulated by automatic, silent or DMX
- Constant temperature readout / management function
- DB rating @ 1M = 54,18db
- 2 x 1/4 turn fastening Omega Clamps
- Electronic ballast and power supply
- Power consumption: 420W max.
- Voltage: AC 100V ~ 240V 50/60Hz
- Dimensions (LxWxH): 409x419x541 mm (Head up)
- Weight: 22,2 kg
